TE Connectivity – 206136-1 – Connector, circular. 7 Position Plug Low Price

TE Connectivity – 206136-1 Connector, circular.

Circuit count: 7 Position.

Housing material: Thermoplastic.

Mounting type: Cable mount.

Shell Size: 23.

Contact type: 23-7.

Body Material: Glass, Nylon, Polyamide, Thermoplastic

Contact Material: Copper

Housing Material: Nylon

Insulation Material: Thermoplastic

Mount: Panel

Current Rating: 25 A

Fastening Type  Threaded

Insulation Resistance: 5 GΩ

Operating Supply Voltage: 600 V

Orientation: Straight

Dimensions: Insulation Diameter 5.588 mm, Length 41.78 mm

Note: CPC Series.

No actual contacts.
